P4000 OF 3% series

Benefits of Solar Screen Shades by Bestex

  • • Solar protection with a better view
  • • High quality
  • • Reduced glare and brightness
  • • A full range of shade cloth colors to control brightness, glare, visibility
  • • Energy saving, Eco friendly
    • P4000 OF 3%

      P4107

    • P4000 OF 3%

      P4109

    • P4000 OF 3%

      P4111

    • P4000 OF 3%

      P4112

    • P4000 OF 3%

      P4201

    • P4000 OF 3%

      P4202

    • P4000 OF 3%

      P4205

    • P4000 OF 3%

      P4211

    • P4000 OF 3%

      P4212

    • P4000 OF 3%

      P4213

P4000 OF 3%

Composition

30% Polyester, 70% PVC

Weight

550 g/m2 +/-5%

Thickness

0.70 mm+/-5%

Width

1830mm/2500mm/3000mm/3200mm/2000mm

Openness

Average 3%

Breaking Strength

Warp≥2600N/5cm / Weft≥2500N/5cm

Color Fastness

Grade 8

UV Blockage

Appox.97%

Fire Resistance

NFPA 701-2015(USA),BS5867(UK), DIN  4102-1(GERMANY)


Solar Properties:

Ref.No TS RS AS TV 1/8CL
P4201 17 70 13 16 0.31
P4202 19 55 26 18 0.42
P4205 13 43 44 15 0.49
P4211 8 7 85 12 0.72
P4212 8 9 83 12 0.71
P4213 7 3 90 11 0.75

TS: Solar Transmittance

RS: Solar Reflectance

AS: Solar Absorbance

TV: Visible Light Transmittance
